WTP卧式高效节能水泵

分类：

爱皮尔专业工程师为您

  • 免费提供一对一技术支持服务
  • 特殊材质、非常规产品均可订做
  • 服务热线：021-5810 8666
  • E-mail：business@cnapl.com

WTP卧式节能水泵，是一种特殊泵，流量比普通水泵大，要求管路前端有足够的水给它供应。对管路设计和布置比较严格，按以下几点要求布置，节能效果越明显。

  1. 管路前后端的管径比所选水泵口径规格较小大一号;
  2. 水平管路用异径大小头来变径;
  3. 节能泵前后端要安装阻力比较小的闸阀，不要安装蝶阀;
  4. 水泵要求单台使用，如一用一备配置或二台轮流使用、一台备用。在泵组运行过程，通过注意细节、挖掘能效的做法，实现操作挖潜、状态运行振动监测动态原理，进一步控制资源和能源的浪费。加强现场维护和管理任何机器都需要进行维护和保养。

选型范围

流量：9-1200m3/h；
扬程：14-55m；
介质：清水或物理化学性质类似于清水的其它液体；
介质温度：-10°C- +105°C之间；
环境温度：≤40°C(海拔高度小于1000m时相对温度不超过95％)；
工作压力：≤1.6MPa。

产品详情

结构图纸

产品特点

适用场景

型号意义

故障排除

故障现象 产生原因 排除方法
针剧烈跳动
1.泵不吸水出口压力表及真空表指		 a)泵内灌水量不够
b)吸水管路或密封仪表漏水
c)泵起动时出口阀门开启太大
d)底阀淹没深度不够
e)泵内没灌满水、有空气
f)进水管路漏气
g)进水管路安装不对，堵气
h)出口处堵气，逆止阀不能打开		 a)检查底阀是否漏水并重新灌水
b)找出泄露部位并紧固
c)起动时出口闸阀关闭，转速正常后慢慢开启出口阀门
d)调整淹没深度至1.5倍进水管径以上
e)检查底阀是否漏水并重新安装灌水
f)密封漏气的部位
g)重新安装进水管路
h)排气
2.泵不吸水，真空表显示高度真空 a)底阀无法打开或已淤塞
b)过滤器，吸入管堵塞
c)吸程过高		 a)校正更换底阀
b)拆卸并清除异物
c)降低吸程
3.泵不出水压力表显示有压力 a)出口管阻太大，止回阀等阀门未打开
b)电机反转
c)叶轮堵塞		 a)减小管阻，更换阀门
b)正确接好电机配线
c)清除异物
4.机组不能起动 a)不具备起动条件
b)电机发生故障		 a)检测是否符合起动条件
b)检测修理电机
5.达不到设计流量及扬程 a)有空气吸入
b)叶轮、进出水管路、过滤器部分阻塞
c)水位降低，淹没深度不够
d)转速不够		 a)检查是否有空气吸入并避免
b)拆卸并清除异物
c)加深淹没深度
d)检查电源频率
6.机械密封漏水 a)介质含有颗粒或液体出现结晶现象
b)机械密封安装不平整
c)机械密封动静环表面无水干磨
d)正常磨损
e)O型圈损坏
f)动环、静环接触压力不够
g)动环、静环接触压力太大、造成过早磨损
h)电机轴窜动		 a)清洗管路，防止结晶
b)重新安装平整
c)泵起动时放尽泵内空气，以防机封干摩擦
d)更换机封
e)更换O型圈
f)重新调整
g)重新调整
h)找出窜动原因并排除
7.轴承过热 a)轴承内油脂流失
b)润滑油老化
c)轴承有故障		 a)补充润滑油
b)更换润滑油
c)检查、修理或更换
8.水泵噪声及振动 a)泵及管路有空气未排除
b)水泵偏离设计工况运行
c)水泵超负荷运行
d)轴承缺油或磨损
e)泵及管路支撑不良
f)泵发生汽蚀		 a)排除空气
b)在设计点附近运行
c)调节阀门减载运行
d)更换轴承补充润滑油
e)加强支撑，采取隔离措施
f)改善吸入条件，避免汽蚀
9.电机超电流 a)泵超大流量运行
b)叶轮与泵体口环擦碰
c)介质混入其他异物
d)电压过低
e)轴承损坏
f)转速过快
g)电缆线绝缘不够
h)电机绝缘不够		 a)调节出口阀门
b)校正泵轴的同心度
c)排除异物
d)使泵在正常电压下运行
e)更换轴承
f)检查电源频率
g)更换
h)改善机组使用环境
10.电机烧毁 a)长时间超负荷运行
b)定子受潮
c)电机缺相运行		 a)调节运行工况
b)改善机组使用环境
c)检查电源，排除故障

产品参数

型号 流量 扬程 效率 轴功率(Kw) 必需汽蚀余量(m) 电机
(m3/h) （L/s） (m) (%) 功率(Kw)
50WTP13-16/2 9 2.5 17 55.9 0.75 2.3 1.1
13 3.61 16 62.4 0.91
15 4.17 14 65.5 0.87
50WTP13-20/2 9 2.5 21 53.5 0.96 2.3 1.5
13 3.61 20 60.3 1.17
15 4.17 19 63.2 1.23
50WTP13-24/2 9 2.5 25 51.1 1.2 1.5
13 3.61 24 58.1 1.46
15 4.17 21 62.2 1.38
50WTP13-28/2 9 2.5 29 49 1.45 2.2
13 3.61 28 56 1.77
15 4.17 26 59.4 1.79
50WTP13-32/2 9 2.5 33 47.1 1.72 2.2
13 3.61 32 54.2 2.09
15 4.17 30 57.6 2.13
50WTP13-36/2 9 2.5 37 45.5 1.99 3
13 3.61 36 52.5 2.43
15 4.17 34 56.3 2.47
50WTP13-44/2 9 2.5 45 39.7 2.78 4
13 3.61 44 50.3 3.1
15 4.17 42 53.4 3.21
50WTP13-50/2 9 2.5 51 37.8 3.31 4
13 3.61 50 47.2 3.75
15 4.17 49 50.9 3.93
50WTP13-60/2 9 2.5 61 36 4.15 5.5
13 3.61 60 41.3 5.14
15 4.17 56 48.4 4.73
50WTP13-70/2 9 2.5 72 33.4 5.28 7.5
13 3.61 70 40.8 6.07
15 4.17 64 44.1 5.93
50WTP13-80/2 9 2.5 82 30.8 6.53 7.5
13 3.61 80 39.1 7.24
15 4.17 77 42.1 7.47
50WTP25-16/2 18 5 17 66.4 1.26 2.2
25 6.94 16 70.4 1.55 2.5
30 8.33 14 72 1.59
50WTP25-20/2 18 5 22 64.3 1.68 2.2
25 6.94 20 69.4 1.96
30 8.33 18 71.5 2.06
50WTP25-24/2 18 5 25 62.9 1.95 3
25 6.94 24 68.1 2.4
30 8.33 22 70.5 2.55
50WTP25-28/2 18 5 30 60.4 2.43 3
25 6.94 28 66.7 2.86
30 8.33 24 69.9 2.81
50WTP25-32/2 18 5 34 59.2 2.82 4
25 6.94 32 65.3 3.34
30 8.33 30 68.2 3.59
50WTP25-38/2 18 5 40 57.2 3.43 5.5
25 6.94 38 62.8 4.12
30 8.33 34 66.8 4.16
50WTP25-44/2 18 5 46 55.1 4.09 5.5
25 6.94 44 61.3 4.89
30 8.33 40 64.8 5.04
50WTP25-50/2 18 5 53 52.8 4.92 7.5
25 6.94 50 59.6 5.71
30 8.33 46 63 5.97
50WTP25-60/2 18 5 62 49.8 6.1 11
25 6.94 60 56.6 7.22
30 8.33 57 59.9 7.77
50WTP25-70/2 18 5 72 45.4 7.77 11
25 6.94 70 54.6 8.73
30 8.33 68 57.7 9.63
50WTP25-80/2 18 5 82 43.6 9.22 15
25 6.94 80 50.7 10.7
30 8.33 78 55.7 11.4
65WTP25-16/2 18 5 17 66.4 1.26 2.5 2.2
25 6.94 16 70.4 1.55
30 8.33 14 72 1.59
65WTP25-20/2 18 5 22 64.3 1.68 2.5 2.2
25 6.94 20 69.2 1.97
30 8.33 18 71.5 2.06
65WTP25-24/2 18 5 25 62.9 1.95 2.5 3
25 6.94 24 67.8 2.41
30 8.33 22 70.5 2.55
65WTP25-28/2 18 5 30 60.4 2.43 2.5 3
25 6.94 28 66.3 2.88
30 8.33 24 69.9 2.81
65WTP25-32/2 18 5 34 59.2 2.82 2.5 4
25 6.94 32 65.1 3.35
30 8.33 30 68.2 3.59
65WTP25-36/2 18 5 40 57.2 3.43 2.5 5.5
25 6.94 38 62.8 4.12
30 8.33 34 66.8 4.16
65WTP25-44/2 18 5 46 55.1 4.09 2.5 5.5
25 6.94 44 61 4.91
30 8.33 40 64.8 5.04
65WTP25-50/2 18 5 53 52.8 4.92 2.5 7.5
25 6.94 50 59.2 5.75
30 8.33 46 63 5.97
65WTP25-60/2 18 5 62 49.8 6.1 2.5 11
25 6.94 60 56.6 7.22
30 8.33 57 60.3 7.72
65WTP25-70/2 18 5 72 45.4 7.77 2.5 11
25 6.94 70 54.6 8.73
30 8.33 66 57.7 9.35
65WTP25-80/2 18 5 82 43.6 9.22 2.5 15
25 6.94 80 50.7 10.7
30 8.33 78 55.7 11.4
65WTP35-16/2 24 6.67 17 69.8 1.59 2.5 2.2
35 9.72 16 73.1 2.09
42 11.7 14 74 2.16
65WTP35-20/2 24 6.67 21.5 68.4 2.05 3
35 9.72 20 72.8 2.62 2.5
42 11.7 19 74 2.94
65WTP35-24/2 24 6.67 26 66.6 2.55 4
35 9.72 24 71.6 3.19
42 11.7 22 73.7 3.41
65WTP35-28/2 24 6.67 30 65.2 3.01 5.5
35 9.72 28 70.9 3.76
42 11.7 27 72.8 4.24
65WTP35-32/2 24 6.67 35 63.4 3.61 5.5
35 9.72 32 69.4 4.39
42 11.7 30 72 4.77
65WTP35-36/2 24 6.67 40 61.6 4.24 5.5
35 9.72 36 68.3 5.02
42 11.7 33 71.4 5.29
65WTP35-44/2 24 6.67 46 59.7 5.04 7.5
35 9.72 44 66 6.35
42 11.7 40 69.6 6.57
65WTP35-50/2 24 6.67 53 57.7 6 11
35 9.72 50 64.2 7.42
42 11.7 48 67.4 8.15
65WTP35-60/2 24 6.67 62 55.9 7.25 11
35 9.72 60 62 9.22
42 11.7 57 65.3 9.98
65WTP35-70/2 24 6.67 72 53.3 8.83 15
35 9.72 70 60 11.1
42 11.7 67 63.1 12.1
65WTP35-80/2 24 6.67 82 48.9 11 15
35 9.72 80 57.7 13.2
42 11.7 77 61.1 14.4
65WTP50-16/2 35 9.72 17 72.9 2.22 3
50 13.9 16 74.9 2.91
60 16.7 14 76.5 2.99
65WTP50-20/2 35 9.72 22 72.1 2.91 4
50 13.9 20 74.9 3.64
60 16.7 18 75.8 3.88
65WTP50-24/2 35 9.72 26 71.1 3.49 5.5
50 13.9 24 74.7 4.37 3
60 16.7 21 75.8 4.53
65WTP50-28/2 35 9.72 31 69.7 4.24 5.5
50 13.9 28 74.1 5.15
60 16.7 24 75.8 5.17
65WTP50-32/2 35 9.72 35 68.5 4.87 7.5
50 13.9 32 73.3 5.94
60 16.7 29 75.2 6.3
65WTP50-36/2 35 9.72 40 67.1 5.68 7.5
50 13.9 36 72.5 6.76
60 16.7 32 75 6.97
65WTP50-44/2 35 9.72 47 65.1 6.88 11
50 13.9 44 70.7 8.47
60 16.7 40 73.5 8.89
65WTP50-50/2 35 9.72 53 63.6 7.94 11
50 13.9 50 69.3 9.82
60 16.7 47 72.1 10.7
65WTP50-60/2 35 9.72 62 61.6 9.59 15
50 13.9 60 67.1 12.2
60 16.7 57 70.2 13.3
65WTP50-70/2 35 9.72 73 59.1 11.8 18.5
50 13.9 70 65 14.7
60 16.7 67 68 16.1
65WTP50-80/2 35 9.72 83 57.2 13.8 22
50 13.9 80 63.2 17.2
60 16.7 77 66.2 19
65WTP18-16/4 14 3.89 17 51.3 1.26 1.5
18 5 16 56.8 1.38 2.5
21 5.83 15 60.1 1.43
65WTP18-20/4 14 3.89 21 47.8 1.68 2.2
18 5 20 53.8 1.82
21 5.83 19 56.8 1.91
65WTP18-24/4 14 3.89 25 42 2.27 3
18 5 24 51.2 2.3
21 5.83 23 54 2.44
65WTP18-28/4 14 3.89 29 41.2 2.68 4
18 5 28 45.4 3.02
21 5.83 26 52.4 2.84
65WTP18-32/4 14 3.89 33 39.8 3.16 4
18 5 32 43.6 3.6
21 5.83 31 46.6 3.8
65WTP25-16/4 15 4.17 17 52.9 1.31 2.2
25 6.94 16 62.2 1.75 3
30 8.33 14 66.4 1.72
65WTP25-20/4 15 4.17 21 49.9 1.72 3
25 6.94 20 59.6 2.28
30 8.33 19 62.4 2.49
65WTP25-24/4 15 4.17 25 44.1 2.32 3
25 6.94 24 56.6 2.89
30 8.33 21 61.1 2.81
65WTP25-28/4 15 4.17 29 42.2 2.81 4
25 6.94 28 54.6 3.49
30 8.33 26 58.6 3.62
65WTP25-32/4 15 4.17 33 41.7 3.23 5.5
25 6.94 32 50.7 4.3
30 8.33 31 56.3 4.5
65WTP25-38/4 15 4.17 39 37.8 4.21 7.5
25 6.94 38 46.1 5.61
30 8.33 36 53.5 5.5
65WTP25-44/4 15 4.17 45 35.2 5.22 7.5
25 6.94 44 45.6 6.57
30 8.33 42 47.4 7.24
65WTP25-50/4 15 4.17 52 35.2 6.03 11
25 6.94 50 44.1 7.72
30 8.33 47 46.9 8.19
80WTP50-16/2 35 9.72 17 72.9 2.22 3
50 13.9 16 74.9 2.91
60 16.7 14 75.8 3.02
80WTP50-20/2 35 9.72 22 72.1 2.91 4
50 13.9 20 74.9 3.64
60 16.7 18 75.8 3.88
80WTP50-24/2 35 9.72 26 71.1 3.49 5.5
50 13.9 24 74.7 4.37
60 16.7 21 75.8 4.53
80WTP50-28/2 35 9.72 30 70 4.08 5.5
50 13.9 28 74.1 5.15
60 16.7 24 75.8 5.17
80WTP50-32/2 35 9.72 35 68.5 4.87 7.5
50 13.9 32 73.3 5.94
60 16.7 29 75.2 6.3
80WTP50-38/2 35 9.72 40 67.1 5.68 7.5
50 13.9 38 72.1 7.18
60 16.7 34 74.6 7.45
80WTP50-44/2 35 9.72 47 65.1 6.88 11
50 13.9 44 70.7 8.47
60 16.7 42 73.2 9.38
80WTP50-50/2 35 9.72 54 63.6 8.09 11
50 13.9 50 69.3 9.82
60 16.7 46 72.1 10.4
80WTP50-60/2 35 9.72 62 61.6 9.59 15
50 13.9 60 66.8 12.2
60 16.7 54 70.2 12.6
80WTP50-70/2 35 9.72 73 59.1 11.8 18.5
50 13.9 70 65 14.7
60 16.7 67 68 16.1
80WTP50-80/2 35 9.72 83 57.2 13.8 22
50 13.9 80 63.2 17.2
60 16.7 77 66.2 19
80WTP72-16/2 54 15 17 75.3 3.32 5.5
72 20 16 76.6 4.1
90 25 15 77.2 4.76
80WTP72-20/2 54 15 22 75.3 4.3 7.5
72 20 20 76.6 5.12
90 25 18 77.6 5.69
80WTP72-24/2 54 15 26 75 5.1 7.5
72 20 24 76.6 6.14
90 25 22 77.6 6.95
80WTP72-28/2 54 15 31 74.3 6.14 11
72 20 28 76.6 7.17
90 25 26 77.6 8.21
80WTP72-32/2 54 15 35 73.4 7.01 11
72 20 32 76.2 8.23
90 25 30 77.6 9.48
80WTP72-38/2 54 15 41 77.2 7.81 11
72 20 38 75.5 9.87
90 25 34 77.6 10.7
80WTP72-44/2 54 15 46 74 9.14 15
72 20 44 74.5 11.6
90 25 38 77.1 12.1
80WTP72-50/2 54 15 54 69.5 11.4 15
72 20 50 73.5 13.3
90 25 45 76.3 14.5
80WTP72-60/2 54 15 63 67.5 13.7 18.5
72 20 60 71.8 16.4
90 25 56 74.8 18.3
80WTP100-16/2 70 19.4 17 76.5 4.24 7.5
100 27.8 16 77.6 5.62 2.5
120 33.3 15 76.8 5.96
80WTP100-20/2 70 19.4 22 76.5 5.48 7.5
100 27.8 20 78 6.98
120 33.3 17 77.9 7.13
80WTP100-24/2 70 19.4 26 76.5 6.48 11
100 27.8 24 78 8.38 4.5
120 33.3 22 78.7 9.14
80WTP100-28/2 70 19.4 31 76.2 7.76 15
100 27.8 28 78 9.78
120 33.3 26 78.7 10.8
80WTP100-32/2 70 19.4 36 75.7 9.07 15
100 27.8 32 78 11.2
120 33.3 30 78.7 12.5
80WTP100-38/2 70 19.4 41 74.7 10.5 15
100 27.8 38 77.8 13.3 4
120 33.3 35 78.7 14.5
80WTP100-44/2 70 19.4 47 73.9 12.1 18.5
100 27.8 44 77.2 15.5
120 33.3 41 78.7 17
80WTP100-50/2 70 19.4 54 72.5 14.2 22
100 27.8 50 76.5 17.8
120 33.3 46 78.3 19.2
80WTP100-60/2 70 19.4 65 70.7 17.5 30
100 27.8 60 75.2 21.7
120 33.3 56 77.3 23.7
80WTP100-70/2 70 19.4 76 68.4 21.2 30
100 27.8 70 73.8 25.8
120 33.3 66 76.2 28.3
80WTP100-80/2 70 19.4 87 66.9 24.8 37
100 27.8 80 72.4 30.1
120 33.3 75 75 32.7
80WTP30-16/4 22 6.11 17 59.1 1.72 2.2
30 8.33 16 64.5 2.03 3
36 10 14 68.7 2
80WTP30-20/4 22 6.11 21 56.2 2.24 3
30 8.33 20 61.8 2.64
36 10 19 65 2.87
80WTP30-24/4 22 6.11 25 53.7 2.79 4
30 8.33 24 59.5 3.3
36 10 23 62.6 3.6
80WTP30-28/4 22 6.11 29 51.2 3.39 5.5
30 8.33 28 57.7 3.96
36 10 26 61.4 4.15
80WTP30-32/4 22 6.11 33 46.9 4.22 5.5
30 8.33 32 55.7 4.69
36 10 30 59.3 4.96
80WTP50-16/4 35 9.72 17 66 2.46 4
50 13.9 16 71.4 3.05 4
60 16.7 14 74.4 3.07
80WTP50-20/4 35 9.72 22 62.7 3.34 5.5
50 13.9 20 69.1 3.94
60 16.7 18 72.6 4.05
80WTP50-24/4 35 9.72 25 61.6 3.87 5.5
50 13.9 24 67.1 4.87
60 16.7 22 70.6 5.09
80WTP50-28/4 35 9.72 30 59.1 4.84 7.5
50 13.9 28 65 5.87
60 16.7 26 68.6 6.19
80WTP50-32/4 35 9.72 34 57.2 5.67 7.5
50 13.9 32 63.2 6.89
60 16.7 30 66.5 7.37
80WTP50-38/4 35 9.72 40 52.7 7.23 11
50 13.9 38 61.1 8.47
60 16.7 35 64.5 8.87
80WTP50-44/4 35 9.72 46 48.3 9.08 11
50 13.9 44 58.6 10.2
60 16.7 41 62.4 10.7
80WTP50-50/4 35 9.72 53 47.8 10.6 15
50 13.9 50 56.1 12.1
60 16.7 47 60.6 12.7
100WTP100-15/2 70 19.4 18 76.5 4.49 5.5
100 27.8 15 77.3 5.28 4.5
120 33.3 11 75.2 4.78
100WTP100-20/2 70 19.4 23 76.5 5.73 7.5
100 27.8 20 78 6.98
120 33.3 17 77.9 7.13
100WTP100-24/2 70 19.4 27 76.5 6.73 11
100 27.8 24 78 8.38
120 33.3 20 78.7 8.3
100WTP100-28/2 70 19.4 32 76 8.03 11
100 27.8 28 78 9.78
120 33.3 24 78.7 9.97
100WTP100-32/2 70 19.4 36 75.5 9.09 15
100 27.8 32 78 11.2
120 33.3 28 78.7 11.6
100WTP100-38/2 70 19.4 41 74.7 10.5 15
100 27.8 38 77.8 13.3 4
120 33.3 35 78.7 14.5
100WTP100-44/2 70 19.4 48 73.6 12.4 18.5
100 27.8 44 77.2 15.5
120 33.3 40 78.7 16.6
100WTP100-50/2 70 19.4 54 72.5 14.2 22
100 27.8 50 76.5 17.8
120 33.3 47 78.2 19.6
100WTP100-60/2 70 19.4 65 70.5 17.6 30
100 27.8 60 75.2 21.7
120 33.3 57 77.2 24.1
100WTP100-70/2 70 19.4 76 68.4 21.2 30
100 27.8 70 73.8 25.8
120 33.3 65 76.3 27.8
100WTP100-80/2 70 19.4 87 66.8 24.8 37
100 27.8 80 72.4 30.1
120 33.3 75 75 32.7
100WTP50-16/4 35 9.72 17 66 2.46 4
50 13.9 16 71.4 3.05
60 16.7 15 73.8 3.32
100WTP50-20/4 35 9.72 22 62.7 3.34 5.5
50 13.9 20 69.3 3.93
60 16.7 17 72.9 3.81
100WTP50-24/4 35 9.72 25 59.5 4 5.5
50 13.9 24 67.1 4.87
60 16.7 22 70.6 5.09
100WTP50-28/4 35 9.72 29 59.6 4.64 7.5
50 13.9 28 65 5.87
60 16.7 26 68.6 6.19
100WTP50-32/4 35 9.72 33 57.7 5.45 7.5
50 13.9 32 63.2 6.89
60 16.7 29 67.1 7.06
100WTP100-16/4 70 19.4 17 74.7 4.34 7.5
100 27.8 16 77.7 5.61 2.8
120 33.3 14 78.7 5.81
100WTP100-20/4 70 19.4 22 72.3 5.8 7.5
100 27.8 20 76.5 7.12 2.5
120 33.3 18 78.9 7.46
100WTP100-24/4 70 19.4 25 70.9 6.72 11
100 27.8 24 75.2 8.69
120 33.3 22 77.4 9.29
100WTP100-28/4 70 19.4 29 69 8.01 11
100 27.8 28 73.8 10.3
120 33.3 26 76.3 11.1
100WTP100-32/4 70 19.4 34 66.9 9.69 15
100 27.8 32 72.4 12
120 33.3 30 75 13.1
100WTP100-38/4 70 19.4 40 64.8 11.8 18.5
100 27.8 38 70.2 14.7 3
120 33.3 35 73.5 15.6
100WTP100-44/4 70 19.4 46 63.1 13.9 18.5
100 27.8 44 68.4 17.5
120 33.3 40 71.8 18.2
100WTP100-50/4 70 19.4 53 60.8 16.6 22
100 27.8 50 66.7 20.4
120 33.3 46 70 21.5
125WTP160-16/2 112 31.1 17 77.9 6.66 11
160 44.4 16 77.7 8.97 4
192 53.3 15 77.6 10.1
125WTP160-20/2 112 31.1 23 78.4 8.95 15
160 44.4 20 79.1 11 4.5
192 53.3 18 78.3 12
125WTP160-24/2 100 27.8 26 78.4 9.03 15
160 44.4 24 80 13.1 4
192 53.3 22 79.5 14.5
125WTP160-28/2 112 31.1 32 78.4 12.4 18.5
160 44.4 28 80 15.3
192 53.3 24 79.5 15.8
125WTP160-32/2 112 31.1 36 78.4 14 18.5
160 44.4 32 80 17.4
192 53.3 28 80 18.3
125WTP160-38/2 112 31.1 42 78.4 16.3 22
160 44.4 38 80 20.7
192 53.3 34 80.6 22.1
125WTP160-44/2 112 31.1 48 77.6 18.9 30
160 44.4 44 80 24
192 53.3 41 80.6 26.6
125WTP160-50/2 112 31.1 55 78.6 21.3 30
160 44.4 50 80 27.2
192 53.3 46 80.6 29.8
125WTP160-60/2 112 31.1 66 75.5 26.7 37
160 44.4 60 79.2 33
192 53.3 55 80.6 35.7
125WTP160-70/2 112 31.1 76 74.2 31.2 45
160 44.4 70 78.4 38.9
192 53.3 64 80.1 41.8
125WTP160-80/2 112 31.1 87 72.8 36.5 55
160 44.4 80 77.5 45
192 53.3 73 79.6 48
125WTP80-16/4 56 15.6 18 71.8 3.82 5.5
80 22.2 16 76 4.59 2.8
96 26.7 15 77.6 5.05
125WTP80-20/4 56 15.6 23 69.6 5.04 7.5
80 22.2 20 74.5 5.85
96 26.7 18 76.9 6.12
125WTP80-24/4 56 15.6 25 67.9 5.62 7.5
80 22.2 24 72.8 7.18 2.5
96 26.7 21 75.8 7.24
125WTP80-28/4 56 15.6 29 66.1 6.69 11
80 22.2 28 71.2 8.57
96 26.7 26 74.2 9.16
125WTP80-32/4 56 15.6 35 63.7 8.38 11
80 22.2 32 69.5 10
96 26.7 30 72.6 10.8
125WTP120-16/4 84 23.3 17 76.1 5.11 7.5
120 33.3 16 78.7 6.64 3
144 40 14 79.6 6.9
125WTP120-20/4 84 23.3 22 74.2 6.78 11
120 33.3 20 77.9 8.39
144 40 18 79.6 8.87
125WTP120-24/4 84 23.3 26 72.6 8.19 11
120 33.3 24 76.8 10.2
144 40 22 78.9 10.9
125WTP120-28/4 84 23.3 30 70.9 9.68 15
120 33.3 28 75.7 12.1
144 40 26 78 13.1
125WTP120-32/4 84 23.3 35 68.8 11.6 15
120 33.3 32 74.3 14.1
144 40 29 77.2 14.7
125WTP120-38/4 84 23.3 39 67.3 13.3 18.5
120 33.3 38 72.4 17.2
144 40 36 75.6 18.7
125WTP120-44/4 84 23.3 46 65.5 16.1 22
120 33.3 44 70.6 20.4
144 40 41 74 21.7
125WTP120-50/4 84 23.3 53 63.4 19.1 30
120 33.3 50 68.8 23.7
144 40 47 72.1 25.6
125WTP160-16/4 112 31.1 17 78.1 6.64 11
160 44.4 16 80 8.71 3.5
192 53.3 14 80.6 9.08
125WTP160-20/4 112 31.1 22 76.8 8.74 15
160 44.4 20 80 10.9
192 53.3 18 80.6 11.7
125WTP160-24/4 112 31.1 25 75.7 10.1 15
160 44.4 24 79.2 13.2
192 53.3 22 80.6 14.3
125WTP160-28/4 112 31.1 30 74 12.4 18.5
160 44.4 28 78.4 15.6
192 53.3 26 80 17
125WTP160-32/4 112 31.1 34 73 14.2 22
160 44.4 32 77.5 18
192 53.3 30 79.3 19.8
125WTP160-38/4 112 31.1 40 70.9 17.2 30
160 44.4 38 75.8 21.8
192 53.3 36 78.1 24.1
125WTP160-44/4 112 31.1 46 69.1 20.3 30
160 44.4 44 74.4 25.8
192 53.3 41 77 27.8
125WTP160-50/4 112 31.1 52 67.5 23.5 37
160 44.4 50 72.8 29.9
192 53.3 47 75.8 32.4
150WTP200-16/2 140 38.9 18 74.8 9.17 15
200 55.6 16 77.8 11.2 5
240 66.7 14 78.3 11.7
150WTP200-20/2 140 38.9 23 79.4 11 15
200 55.6 20 79 13.8
240 66.7 17 78.3 14.2
150WTP200-24/2 140 38.9 27 79.4 13 18.5
200 55.6 24 80 16.3
240 66.7 21 79 17.4
150WTP200-28/2 140 38.9 32 79.4 15.4 22
200 55.6 28 80.8 18.9
240 66.7 24 80.1 19.6
150WTP200-32/2 140 38.9 35 79.4 16.8 30
200 55.6 32 80.8 21.6
240 66.7 30 81.1 24.2
150WTP200-38/2 140 38.9 42 79.4 20.2 30
200 55.6 38 80.8 25.6
240 66.7 35 81.3 28.1
150WTP200-44/2 140 38.9 48 79.6 23 37
200 55.6 44 80.8 29.7
240 66.7 40 81.3 32.2
150WTP200-50/2 140 38.9 55 78.7 26.6 37
200 55.6 50 80.8 33.7
240 145 45 81.3 36.2
150WTP200-60/2 140 38.9 66 77.6 32.4 45
200 55.6 60 80.7 40.5
240 66.7 55 81.3 44.2
150WTP200-70/2 140 38.9 76 76.5 37.9 55
200 55.6 70 80 47.7
240 66.7 64 81.3 51.5
150WTP200-80/2 140 38.9 87 75.4 44 75
200 55.6 80 79.3 54.9
240 66.7 75 80.7 60.7
150WTP200-16/4 140 38.9 17 79.4 8.16 15
200 55.6 16 80.8 10.8 3
240 66.7 14 81.3 11.3
150WTP200-20/4 140 38.9 22 78.7 10.7 15
200 55.6 20 80.8 13.5
240 66.7 18 81.3 14.5
150WTP200-24/4 140 38.9 25 77.9 12.2 18.5
200 55.6 24 80.6 16.2 3.5
240 66.7 21 81.3 16.9
150WTP200-28/4 140 38.9 30 76.7 14.9 22
200 55.6 28 80 19.1
240 66.7 25 81.3 20.1
150WTP200-32/4 140 38.9 34 75.6 17.1 30
200 55.6 32 79.3 22
240 66.7 29 80.9 23.4
150WTP200-38/4 140 38.9 40 73.8 20.7 30
200 55.6 38 78 26.5
240 66.7 35 80 28.6
150WTP200-44/4 140 38.9 47 71.6 25 37
200 55.6 44 76.8 31.2
240 66.7 38 79.4 31.3
150WTP200-50/4 140 38.9 53 70.1 28.8 45
200 55.6 50 75.4 36.1
240 66.7 46 77.9 38.6
200WTP200-16/4 140 38.9 17 79.4 8.16 15
200 55.6 16 80.8 10.8 3
240 66.7 14 81.3 11.3
200WTP200-20/4 140 38.9 22 78.7 10.7 15
200 55.6 20 80.8 13.5
240 66.7 18 81.3 14.5
200WTP200-24/4 140 38.9 25 77.9 12.2 18.5
200 55.6 24 80.6 16.2 3.5
240 66.7 21 81.3 16.9
200WTP200-28/4 140 38.9 30 76.7 14.9 22
200 55.6 28 80 19.1
240 66.7 25 81.3 20.1
200WTP200-32/4 140 38.9 34 75.6 17.1 30
200 55.6 32 79.3 22
240 66.7 29 80.9 23.4
200WTP200-38/4 140 38.9 40 73.8 20.7 30
200 55.6 38 78 26.5 4.5
240 66.7 35 80 28.6
200WTP200-44/4 140 38.9 47 71.6 25 37
200 55.6 44 76.8 31.2
240 66.7 38 79.4 31.3
200WTP200-50/4 140 38.9 53 70.1 28.8 45
200 55.6 50 75.4 36.1
240 66.7 46 77.9 38.6
200WTP200-60/4 140 38.9 64 67.7 36 55
200 55.6 60 73 44.8
240 66.7 56 75.9 48.2
200WTP200-70/4 145 40.3 72 65.6 43.3 75
200 55.6 70 71.2 53.5
240 66.7 65 74.1 57.3
200WTP200-80/4 140 38.9 85 63.1 51.4 75
200 55.6 80 69.5 62.7
240 66.7 75 72.3 67.8
200WTP300-16/4 220 61.1 18 80.9 13.3 18.5
300 83.3 16 82 15.9 4
360 100 14 81.7 16.8
200WTP300-20/4 220 61.1 23 80.9 17 22
300 83.3 20 82 19.9
360 100 18 82.6 21.4
200WTP300-24/4 220 61.1 27 80.4 20.1 30
300 83.3 24 82 23.9
360 100 22 82.6 26.1
200WTP300-28/4 220 61.1 31 79.8 23.3 30
300 83.3 28 82 27.9
360 100 24 82.6 28.5
200WTP300-32/4 210 58.3 36 78.8 26.1 37
300 83.3 32 81.8 32
360 100 29 82.6 34.4
200WTP300-38/4 220 61.1 41 77.9 31.5 45
300 83.3 38 81.1 38.3
360 100 33 82.6 39.2
200WTP300-44/4 220 61.1 48 76.3 37.7 55
300 83.3 44 80.6 44.6
360 100 37 82.3 44.1
200WTP300-50/4 220 61.1 54 74.9 43.2 55
300 83.3 50 79.2 51.6
360 100 45 81.4 54.2
200WTP300-60/4 220 61.1 64 72.8 52.7 75
300 83.3 60 77.4 63.3 4.5
360 100 54 80.2 66
200WTP300-70/4 220 61.1 74 71 62.4 90
300 83.3 70 76.9 74.4
360 100 64 78.6 79.8
200WTP300-80/4 220 61.1 85 69.2 73.6 110
300 83.3 80 73.9 88.4
360 100 74 77.2 94
200WTP360-14/4 252 70 16 81.5 13.6 18.5
360 100 14 82 16.7 4
432 120 12 80.6 17.5
200WTP400-20/4 280 77.8 22 81.9 20.5 30
400 111.1 20 83 26.2 5
480 133.3 18 83 28.3
200WTP400-24/4 280 77.8 27 81.9 25.1 37
400 111.1 24 83 31.5 4
480 133.3 21 83.5 32.9
200WTP400-28/4 280 77.8 32 81.5 29.9 37
400 111.1 28 83 36.7
480 133.3 23 83.5 36
200WTP400-32/4 280 77.8 36 80.9 33.9 45
400 111.1 32 83 42
480 133.3 28 83.6 43.8
200WTP360-37/4 252 70 42 79.4 36.3 45
360 100 37 82.3 44.1 5
432 120 32 83.2 45.2
200WTP380-40/4 266 73.9 45 79.1 41.2 55
380 105.6 40 82.3 50.3
456 126.7 33 83.4 49.1
200WTP380-43/4 266 73.9 48 78.6 44.2 55
380 105.6 43 82 51.4
456 126.7 36 83.4 53.6
200WTP400-50/4 280 77.8 54 78 52.8 75
400 111.1 50 81.6 66.7
480 133.3 45 83.3 70.6
200WTP360-60/4 252 70 64 74.9 58.6 90
360 100 60 79.4 74.1 4
432 120 53 82.5 75.6
200WTP380-70/4 266 73.9 74 73.7 72.7 110
380 105.6 70 78.4 92.4
456 126.7 63 81.4 96.1
200WTP400-80/4 280 77.8 85 72.6 89.3 132
400 111.1 80 78.9 110.5
480 133.3 72 80.4 117.1
250WTP500-16/4 350 97.2 18 82.6 20.8 30
500 138.9 16 82.3 26.5 5.5
600 166.7 14 81.2 28.2
250WTP500-20/4 350 97.2 22 82.6 25.4 37
500 138.9 20 83.6 32.6
600 166.7 18 82.8 35.5
250WTP480-23/4 336 93.3 25 82.4 27.8 37
480 133.3 23 83.7 35.9
576 160 21 84 39.2
250WTP500-27/4 350 97.2 30 82.6 34.6 45
500 138.9 27 83.7 43.9
600 166.7 22 84.2 42.7
250WTP500-32/4 350 97.2 35 82.4 40.5 55
500 138.9 32 83.7 52.1
600 166.7 28 84.2 54.3
250WTP500-38/4 350 97.2 41 81.7 47.8 75
500 138.9 38 83.7 61.8
600 166.7 35 84.2 67.9
250WTP500-44/4 350 97.2 48 80.9 56.6 75
500 138.9 44 83.6 71.7
600 166.7 38 84.2 73.7
250WTP500-50/4 350 97.2 54 80 64.3 90
500 138.9 50 83 82
600 166.7 45 84.2 87.3
250WTP500-60/4 350 97.2 65 78.3 79.1 110
500 138.9 60 82 99.6
600 166.7 55 83.6 107.5
250WTP500-70/4 350 97.2 74 76.9 91.7 132
500 138.9 70 80.9 117.8
600 166.7 65 82.8 128.3
250WTP500-80/4 350 97.2 84 75.3 106.3 160
500 138.9 80 79.7 136.7
600 166.7 75 81.9 149.6
250WTP650-16/4 455 126.4 18 83.1 26.8 37
650 180.6 16 82 34.5 7
780 216.7 14 81.9 36.3
250WTP650-20/4 455 126.4 22 83.4 32.7 45
650 180.6 20 83.3 42.5
780 216.7 17 81.9 44.1
250WTP650-24/4 455 126.4 27 83.4 40.1 55
650 180.6 24 84.4 50.3 6.5
780 216.7 21 83.4 53.5
250WTP650-28/4 455 126.4 30 83.4 44.6 75
650 180.6 28 84.4 58.7
780 216.7 25 84.5 62.8
250WTP650-32/4 455 126.4 36 83.4 53.5 75
650 180.6 32 84.4 67.1 6
780 216.7 28 84.9 70.1
250WTP650-36/4 455 126.4 38 83.4 56.5 90
650 180.6 36 84.4 75.5
780 216.7 32 84.9 80.1
250WTP650-40/4 455 126.4 44 83 65.7 90
650 180.6 40 84.4 83.9
780 216.7 33 84.9 82.6
250WTP650-45/4 455 126.4 50 82.4 75.2 110
650 180.6 45 84.4 94.4
780 216.7 41 84.9 102.6
250WTP650-50/4 455 126.4 54 82 81.6 132
650 180.6 50 84.4 104.9 5.5
780 216.7 46 84.9 115.1
250WTP650-56/4 455 126.4 59 81.5 89.7 132
650 180.6 56 84 118
780 216.7 47 84.9 117.6
250WTP650-65/4 455 126.4 68 80.4 104.8 160
650 180.6 65 83.4 138
780 216.7 61 84.7 153
250WTP650-72/4 455 126.4 75 79.4 117 185
650 180.6 72 82.8 153.9 5.2
780 216.7 68 84.2 171.5
250WTP650-80/4 455 126.4 85 78.1 134.9 200
650 180.6 80 82 172.7
780 216.7 73 83.9 184.8
300WTP720-16/4 504 140 18 83 29.8 45
720 200 16 81.8 38.4 7.5
864 240 14 82.2 40.1
300WTP720-20/4 504 140 22 83.7 36.1 55
720 200 20 83.3 47.1
864 240 18 82.2 51.5
300WTP720-24/4 504 140 27 83.7 44.3 75
720 200 24 84.3 55.8 7
864 240 20 83 56.7
300WTP720-28/4 504 140 31 83.7 50.8 75
720 200 28 84.8 64.7
864 240 23 84.3 64.2
300WTP720-32/4 504 140 35 83.7 57.4 90
720 200 32 84.8 74
864 240 28 85 77.5
300WTP700-38/4 490 136.1 41 83.6 65.4 90
700 194.4 38 84.7 85.5 6.5
840 233.3 32 85.1 86
300WTP720-44/4 504 140 47 83.3 77.4 110
720 200 44 84.8 101.7
864 240 36 85.2 99.4
300WTP720-50/4 504 140 54 82.7 89.6 132
720 200 50 84.7 115.7
864 240 44 85.2 121.5
300WTP720-60/4 504 140 64 81.7 107.5 160
720 200 60 84.3 139.6 6
864 240 52 85.2 143.6
300WTP720-70/4 504 140 74 80.5 126.2 185
720 200 70 83.6 164.2
864 240 61 85.2 168.5
300WTP720-80/4 504 140 85 79.2 147.3 200
720 200 80 82.8 189.4
864 240 70 84.6 194.7
300WTP1000-16/4 700 194.4 18 82.7 41.5
1000 277.8 16 82.6 52.8 5.1 55
1200 333.3 14 83.1 55.1
300WTP1000-18/4 700 194.4 20 83.2 45.8
1000 277.8 18 82.7 59.3 5.3 75
1200 333.3 16 83.1 62.9
300WTP1000-20/4 700 194.4 23 84.1 52.1
1000 277.8 20 82.6 65.9 5.5 75
1200 333.3 18 83.1 70.8
300WTP1000-24/4 700 194.4 26 84.6 58.6
1000 277.8 24 83.9 77.9 4.6 90
1200 333.3 22 83.1 86.5
300WTP950-27/4 665 184.7 31 84.5 66.4
950 263.9 27 84.8 82.4 4.8 90
1140 326.7 24 83.7 89
300WTP1000-32/4 700 194.4 36 84.6 81.1
1000 277.8 32 85.6 101.8 6.5 110
1200 333.3 28 84.5 108.3
300WTP1200-32/4 840 233.3 35 85.3 93.9 6.5 132
1200 333.3 32 85.3 122.6
1440 400 28 83.4 114.3
300WTP1000-38/4 700 194.4 42 84.6 94.6
1000 277.8 38 85.7 120.8 3.9 132
1200 333.3 33 85.5 126.1
300WTP1000-45/4 700 194.4 48 84.6 108.2
1000 277.8 45 85.7 143 8 160
1200 333.3 40 86.1 151.8
300WTP1000-50/4 700 194.4 55 84.5 124.1
1000 277.8 50 85.7 158.9 8 185
1200 333.3 42 86.1 159.4
350WTP1200-38/4 840 233.3 41 85.3 110 160
1200 333.3 38 85.3 145.6 6.5
1440 388.9 31 84.3 143.4
350WTP1200-50/4 840 233.3 53 85.3 142.1 220
1200 333.3 50 86.1 189.8 6.5
1440 400 44 86.4 199.7
350WTP1200-20/6 840 233.3 23 85.3 61.7 90
1200 333.3 20 85.7 76.3 4.5
1440 400 16 84 79.4
350WTP1400-24/6 1050 291.7 26 85.8 86.7 132
1400 388.9 24 86.4 105.9 4.5
1580 438.9 19 85 96.2
350WTP1600-32/4 1120 311.1 35 85.9 124.3 185
1600 444.4 32 84.7 164.6 7
1920 533.3 25 87.1 150.1
350WTP1600-45/4 1120 311.1 48 85.9 170.4 7 250
1600 444.4 45 86.6 226.4
1920 533.3 40 85.8 243.8
350WTP1600-16/6 1120 311.1 18 85.3 64.4 4.5 90
1600 444.4 16 83.7 83.3
1920 533.3 13 87.1 78
350WTP1500-32/6 1050 291.7 35 86.1 116.2 4.5 160
1500 416.7 32 86.7 150.8
1800 500 25 86.2 142.2
400WTP1600-32/4 1120 311.1 35 85.9 124.3 6.5 185
1600 444.4 32 84.7 164.6
1920 533.3 25 87.1 150.1
400WTP1600-20/6 1120 311.1 23 85.9 81.7 4.5 132
1600 444.4 20 85.2 102.3
1920 533.3 16 87.1 96.1
400WTP2000-32/4 1400 388.9 35 85.5 156.1 6.5 250
2000 555.6 32 84.2 207
2400 666.7 25 87.5 186.7
400WTP2000-44/4 1400 388.9 48 86.3 212.1 6.5 315
2000 555.6 44 86.3 277.7
2400 666.7 36 84.5 278.5
400WTP2000-20/6 1400 388.9 23 86.2 101.7 5 160
2000 555.6 20 84.8 128.5
2400 666.7 16 87.5 119.5
400WTP2000-24/4 1400 388.9 26 86.3 114.9 5 185
2000 555.6 24 86 152
2400 666.7 19 87.5 141.9
400WTP2000-12/8 1400 388.9 13 85.1 58.2 3.5 90
2000 555.6 12 83.8 78
2400 666.7 10 87.5 74.7

相关产品

滚动至顶部
